Nial Sheets and Plates, Houston, USA, is a well-established manufacturer and supplier that takes pride in its commitment to quality and accuracy. It is a specialist in high-quality sheets and plates for industrial applications and also provides Stainless Steel 317 Angles, which are known for their high resistance to corrosion, strength, and durability. Through its emphasis on innovation, performance, and customer satisfaction, the organization provides custom stainless steel solutions for demanding sectors such as construction, marine, and medical applications. Supported by sophisticated manufacturing processes and a global customers base, Nial Sheets and Plates is a trusted partner for high-performance stainless steel solutions.
Stainless Steel 317 Angle is an anticorrosion austenitic steel alloy consisting of chromium (18–20%), nickel (11–15%), molybdenum (3–4%), and minimum carbon content, which increases considerably its resistance to chemical attack in acidic and chloride-containing environments. This alloy provides a tensile strength around 515 MPa, yield strength of 205 MPa, and elongation of 35%. Its high molybdenum content provides improvement in pitting, crevice corrosion, and stress corrosion cracking resistance. Having good weldability and formability, Stainless Steel 317 is best suited for harsh and corrosive industrial environments, guaranteeing long-term performance and reliability.
| Specifications | : | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 317 Angle | : | 5mm to 9mm |
| SS 317 Channel | : | 40mm*20mm~300mm*300mm |
| SS 317 Beam | : | 3″ thru 12.31″ |
| SS 317 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317 | 1.4449 | S31700 | SUS 317 | – |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nial Sheets and Plates based in Houston, USA, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 317 angle provides excellent corrosion resistance, especially in chloride and acidic environments, making it ideal for extreme conditions and extremely durable, retaining its strength and its integrity at elevated temperatures. The alloy is resistant to pitting and crevice corrosion, increasing its longevity in harsh applications. Stainless steel 317 is easily manufactured and welded, providing versatility for a variety of architectural and industrial applications. Its excellent performance in pharmaceutical, food processing and marine environments makes it reliable for applications requiring high resistance loss.
Stainless Steel 317 Angles are greatly prized in industries where chemical exposure, corrosion, and thermal stress are common. They best apply in the chemical processing, pharmaceutical, food and beverage, and marine industries because they can resist chloride solutions, sulfuric acid, and oxidizing agents. Typical applications are exhaust systems, pressure vessels, heat exchangers, and piping systems. Resistance to crevice and pitting corrosion also renders them appropriate for harsh environment aerospace, construction, and auto components. Stainless Steel 317 offers resistant structural support with superior durability in turbulent or high-temperature environments.
