Nial Sheets and Plates is a reputable manufacturer and supplier of Stainless Steel 409 Sheets and Plates, proudly based in Houston, USA. They specialize in providing durable and cost-effective solutions tailored for a variety of industrial and automotive needs. Stainless Steel 409 is a titanium-stabilized, ferritic grade that stands out for its impressive resistance to exhaust gases and atmospheric corrosion, along with good weldability. Nial ensures that their sheets and plates meet international quality standards, catering to industries like automotive, heat exchangers, and construction. With a commitment to timely delivery and precision, Nial offers Stainless Steel 409 products designed for long-lasting performance and structural integrity.
The composition of Stainless Steel 409 Sheets and Plates primarily includes iron and chromium (10.5–11.75%), along with small amounts of carbon, manganese, silicon, and titanium for stabilization. This ferritic alloy is known for its decent oxidation resistance and moderate corrosion resistance, particularly in less aggressive environments. Typically, its mechanical properties feature a tensile strength ranging from 380 to 550 MPa and a yield strength of about 170 MPa, showcasing moderate ductility and excellent formability. The titanium content plays a crucial role in preventing intergranular corrosion, especially after welding or extended exposure to high temperatures.
| Standards | ASTM A240 / ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 0.01~200mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | the surface and finish of stainless steel 409 sheet: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mg | Ph | Si | Sl | Cr | Ti | Ni |
| 409 min 409 max | – 0.08 | – 1 | – 0.045 | – 1 | – 0.045 | 10.5 11.75 | 6xC – | – 0.5 |
| Density (lb / cu. in.) | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Modulus of Elasticity Tension |
| 0.278 | 7.86 | 0.11 | 29 |
| Grade | WERKSTOFF NR. | AISI | UNS | AFNOR | BS | GOST | JIS |
| SS 409 | 1.4512 | 409 | S40900 | Z3CT12 | 409 S 19 | SUH 409 | – |
|
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion (μm/m/°C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Electrical Resistivity (nΩ.m) |
|||
|
0-100°C |
0-315°C |
0-538°C |
at 100°C |
at 500°C |
|||||
|
409 |
7800 |
200 |
11.0 |
11.7 |
12.4 |
25.8 |
27.5 |
460 |
600 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 409 Sheets and Plates find extensive use in applications where heat resistance and corrosion protection are essential, all while keeping costs manageable. In the automotive sector, they are commonly utilized for exhaust systems, mufflers, catalytic converter shells, and tailpipes due to their heat resistance and durability. Additionally, they are employed in HVAC systems, heat exchangers, and industrial ducting. In construction, 409 sheets are ideal for roofing, cladding, and structural applications where aesthetics and weather resistance are key. Their excellent formability and weldability make them a go-to choice for fabrication and assembly across various industries.
Stainless steel 409 sheets and plates are commonly used in automotive, construction, and industrial applications because of their corrosion resistance, heat resistance, and excellent durability and are widely used in exhaust systems, products a heating, and in the automotive industry. Additionally, they are used in construction buildings, pressure vessels and chemical devices. Stainless Steel 409 is cost-effective compared to other types of stainless steel, making it suitable for applications requiring durability and resistance to oxidation at high temperatures, such as heat exchangers and furnace components.
