Nial Sheets and Plates stands out as a leading manufacturer and supplier of top-notch Stainless Steel 310 Sheets and Plates, proudly based in Houston, USA. Known for their heat-resistant and corrosion-resistant stainless steel products, Nial caters to industries that thrive in extreme conditions. The company is committed to upholding strict quality standards, ensuring precise fabrication, and delivering on time, making them a reliable partner for a variety of applications—from high-temperature processing to structural fabrication. Nial Sheets and Plates is all about providing durable, dependable, and competitively priced Stainless Steel 310 Sheets and Plates for those demanding industrial projects.
Stainless Steel 310 Sheets and Plates are austenitic chromium-nickel steels that boast around 24–26% chromium and 19–22% nickel, which gives them exceptional oxidation resistance and high-temperature strength. This grade has a density of 7.9 g/cm³, a tensile strength of about 520 MPa, and a yield strength close to 205 MPa, with an elongation of roughly 40%. Even at elevated temperatures, it maintains good ductility and toughness, resisting thermal fatigue and scaling. Stainless Steel 310 is specifically designed for environments that experience frequent heating and cooling cycles, offering excellent weldability and formability for critical high-temperature applications.
| Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L , 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L |
| Thickness | 0.3mm – 100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Type of Material | STAINLESS STEEL SOFT, DEEP DRAW, EXTRA DEEP DRAW, QUARTER HARD, HALF HARD, FULL HARD. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Sheets & Plates, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
|
Element |
Percent by Weight |
|
Type 301 ANN |
|
|
Carbon |
0.150 maximum |
|
Manganese |
2.000 maximum |
|
Phosphorus |
0.045 maximum |
|
Sulfur |
0.030 maximum |
|
Silicon |
1.00 maximum |
|
Chromium |
16.00 – 18.00 |
|
Nickel |
6.000 – 8.000 |
|
Nitrogen |
0.10 maximum |
|
Properties |
Metric |
Imperial |
|---|---|---|
|
Tensile strength |
515 MPa |
74694 psi |
|
Yield strength |
275 MPa |
39900 psi |
|
Elastic modulus |
207 GPa |
30000 ksi |
|
Poisson’s ratio |
0.27-0.30 |
0.27-0.30 |
|
Elongation at break |
40% |
40% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 301 | 1.4310 | S30100 | SUS 301 | – | – | – | – |
|
Physical Property |
Value |
||
|---|---|---|---|
|
Density |
0.2850 lb/in³ (7.88g/cm³) |
||
|
Melting Range |
2250-2950°F (1399-1421°C) |
||
|
Specific Gravity |
8.03 |
||
|
Modulus of Elasticity in Tension |
28•106 psi (193 GPa)* |
|
Temperature Range |
Mean Coefficient of Thermal Expansion |
||
|
°C |
°F |
cm/cm°C |
in/in/°F |
|
20-100 |
68-212 |
16.6·10-6 |
9.2·10-6 |
|
20-300 |
68-572 |
17.6·10-6 |
9.8·10-6 |
|
20-500 |
68-932 |
18.6·10-6 |
10.3·10-6 |
|
20-700 |
68-1292 |
19.5·10-6 |
10.8·10-6 |
|
20-871 |
68-1600 |
19.8·10-6 |
11.0·10-6 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 301 sheets and plates have many advantages, including exceptional corrosion resistance, making them ideal for harsh environments Their high strength and extremely durable work performance endure heavy mechanical stresses and remain stable. This makes them suitable for use in a variety of industries, including aviation, automotive, and construction. The excellent weldability and ease of fabrication of the alloy provide its versatility for various applications. Additionally, stainless steel 301 is highly resistant to oxidation and can maintain its strength at elevated temperatures, providing long-term and reliable service.
These Stainless Steel 310 Sheets and Plates are commonly found in furnace parts, heat treatment baskets, kilns, and combustion chambers, thanks to their superior heat resistance and durability. They’re perfect for thermal processing industries, petrochemical plants, and power generation facilities where materials need to endure high temperatures and oxidation. Additionally, these sheets and plates are used in food processing equipment, oil refinery components, and cement manufacturing. Their outstanding weldability and corrosion resistance make them ideal for structural components that face severe thermal cycling, ensuring reliable performance even in the harshest industrial environments.
