Nial Sheets and Plates stands out as a top-notch manufacturer and supplier of Titanium Gr 2 Sheets and Plates right in Houston, USA. They’ve built a solid reputation for providing high-quality titanium products that cater to a variety of industrial needs. Focusing on Titanium Gr 2, the company delivers sheets and plates that boast impressive corrosion resistance, excellent formability, and dependable strength. Thanks to their advanced manufacturing processes and rigorous quality control, Nial Sheets and Plates guarantees precise dimensions, smooth surfaces, and timely deliveries. Industries such as chemical processing, marine, aerospace, medical, and architecture rely on Nial Sheets and Plates for trustworthy Titanium Gr 2 solutions tailored to their specific requirements.
When it comes to Titanium Gr 2 Sheets and Plates, these materials are commercially pure, containing around 99.2% titanium along with trace amounts of oxygen (maximum 0.25%), iron (maximum 0.30%), carbon, nitrogen, and hydrogen. They offer a minimum tensile strength of 344 MPa and a yield strength of 275 MPa, with an impressive elongation of about 20%. With a density of 4.51 g/cm³, they provide an outstanding strength-to-weight ratio. These sheets and plates are known for their remarkable corrosion resistance, good ductility, and ease of welding, making them ideal for forming and fabrication in various moderate-strength, corrosion-sensitive environments.
| Specifications | ASTM B265/ ASME SB265 |
|---|---|
| Size | 1000 x 2000 milimeter, 1220 x 2440 milimeter, 1500 x 3000 milimeter, 2000 x 2000 milimeter, 2000 x 4000 milimeter |
| Thickness | 0.1 to 12 milimeter |
| Form | Plates, Sheet, Slatting Coils, Coils, Foils, Plain Sheet, Shim Sheet, Strip, Rolls, Perforated Coils, Flats, Blank , Ring |
| Finish | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade 2 Sheet & Plate | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Titanium Gr. 2 Sheet & Plate | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Titanium Grade 2 sheets and plates offer excellent corrosion resistance, particularly in marine and chemical environments, making them ideal for aerospace, chemical processing, and marine industries. They are lightweight yet exceptionally strong, providing a high strength-to-weight ratio. Known for their biocompatibility, they are widely used in medical applications. Titanium Grade 2 also has good weldability, formability, and resistance to high temperatures, making it versatile for various applications. Additionally, it exhibits low thermal expansion, enhancing stability in challenging environments.
| Stocked Sizes | |
|---|---|
| Size (in inches) | Size (in ) |
| .125 | 3.18 |
| .134 | 3.40 |
| .156 | 3.96 |
| .187 | 4.75 |
| .250 | 6.35 |
| .312 | 7.92 |
| .375 | 9.53 |
| .500 | 12.7 |
| .600 | 15.9 |
| .750 | 19.1 |
| .875 | 22.2 |
| 1 | 25.4 |
| 1.125 | 28.6 |
| 1.250 | 31.8 |
| 1.500 | 38.1 |
| 1.750 | 44.5 |
| 2 | 50.8 |
| 2.500 | 63.5 |
| 3 | 76.2 |
Titanium Gr 2 Sheets and Plates find extensive use in industries that need lightweight, corrosion-resistant materials. You’ll often see them in applications like heat exchangers, pressure vessels, condenser tubing, and chemical processing equipment. They’re also utilized in marine components, such as seawater desalination systems and ship parts, thanks to their excellent resistance to saltwater corrosion. In aerospace, they’re used for airframe skins and ductwork. The medical field benefits from Titanium Gr 2 in surgical instruments and implants, while its formability and biocompatibility make it a great choice for architectural panels, automotive parts, and precision-engineered components.
