Nial Sheets and Plates, with its headquarters in Houston, USA, is a reliable producer and distributor of superior metal solutions designed to satisfy world industry needs. As a titanium foil, sheet, and plate specialist, we cater to important industries such as aerospace, medical, and industrial usage. Our titanium foils are famous for being lightweight yet stronger than conventional materials, possessing superior corrosion resistance, and dimensional stability, providing reliable performance under high-stress conditions. Supported by advanced manufacturing and adherence to global standards, Nial Sheets and Plates—also referred to as Aaron—is a provider of cost-effective, tailored solutions that are designed to provide reliability, performance, and long-term value for our clients across the globe.
Titanium foils are produced from commercially pure titanium or titanium alloys like Ti-6Al-4V (Grade 5), which comprise about 90% titanium, 6% aluminum, and 4% vanadium. These foils have high tensile strength (as high as 1100 MPa), low density (4.51 g/cm³), and superior corrosion and fatigue resistance. They have a melting point of 1668°C and superior thermal stability and function effectively in corrosive and high-temperature conditions. Also, they are biocompatible and can be used in medical applications. Titanium foils possess strength, flexibility, and durability and are therefore suitable for advanced technical and structural applications.
Standards : ASTM B265 / ASME SB265
Width : 3.2mm – 1500mm
Form : Coils, Foils, Rolls, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Thickness : 0.1mm to 12 mm Thk
Length : 500mm to 12000mm
Width : 100mm to 3000mm
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 240 | 170 | 24 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nial Sheets and Plates based in Houston, USA, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Titanium foils offer numerous advantages, making them a preferred choice across industries. They are incredibly lightweight yet provide exceptional strength and durability, ideal for applications where weight reduction is critical. Their outstanding corrosion resistance makes them suitable for harsh environments, including marine and chemical industries. Titanium foils also excel in high-temperature stability and thermal conductivity, essential for aerospace and automotive applications. Additionally, they are biocompatible, making them perfect for medical implants and devices. Their flexibility, recyclability, and long-lasting performance further enhance their value in diverse industrial and technological uses.
| Size (mm) | Weight per (Kg) | Size (mm) | Weight per (Kg) |
|---|---|---|---|
| 2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
| 3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
| 3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
| 2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
| 3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
| 2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
| 2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
| 2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
| 2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
| 3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
| 2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
Yes, we offer custom sizes for Titanium Foils to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Titanium foils find large-scale applications in industries due to their light weight, corrosion resistance, and strength. They find applications in aircraft skins, engine parts, and insulation layers in the aerospace industry. The medical industry applies them to make implants, prosthetics, and surgical tools because they are non-toxic and biocompatible. In automobile applications, they are used to increase performance in exhaust systems, heat shields, and engine components. Titanium foils also play vital functions in naval constructions and chemical processing hardware where exposure to adverse conditions is the norm. They are also utilized in electronics, battery technology, and building facades for their toughness and aesthetic flexibility.
