Nial Sheets and Plates is a trusted manufacturer and supplier based in Houston, USA, specializing in premium-quality metal solutions. Renowned for expertise in titanium and other advanced materials, the company offers a wide range of products tailored to diverse industrial needs. Notably, their Titanium Grade 5 Foils stand out for their exceptional strength, lightweight properties, and corrosion resistance, making them ideal for aerospace, automotive, and medical applications. Aaron delivers unmatched quality and customer satisfaction, ensuring reliability and innovation in every product.
Standards : ASTM B265 / ASME SB265
Width : 3.2mm – 1500mm
Form : Coils, Foils, Rolls, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Thickness : 0.1mm to 12 mm Thk
Length : 500mm to 12000mm
Width : 100mm to 3000mm
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 5 | 3.7164 / 3.7165 | R56400 |
| Grade | C | Ti | O | Fe | Ai | V |
| Titanium Gr. 5 | 0.25 max | 90 min | 0.2 max | 0.25 max | 6 min | 4 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
Titanium Grade 5 Foil (Ti-6Al-4V) consists of around 90% titanium, 6% aluminum, and 4% vanadium, forming an alloy that is high in strength, low in density, and corrosion resistant. It provides tensile strength of 900–1100 MPa, yield strength of about 830 MPa, and elongation of 10–15%. The alloy is resistant to high temperatures, possessing high fatigue strength and being biocompatible, thus appropriate for medical and aerospace use. Titanium Grade 5 is capable of sustaining its mechanical properties when subjected to severe stress, providing outstanding performance in high-stress, safety-reliant applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nial Sheets and Plates based in Houston, USA, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Titanium Grade 5 Foils offer numerous advantages, including exceptional strength-to-weight ratio, making them ideal for lightweight yet durable applications. They exhibit outstanding corrosion resistance, even in harsh environments like seawater and chemicals, ensuring longevity and reliability. Additionally, Grade 5 titanium is highly biocompatible, making it perfect for medical implants and devices. The alloy also maintains high strength at elevated temperatures, offering excellent performance in aerospace and automotive sectors. Its fatigue resistance, low thermal expansion, and resistance to wear and stress make it a versatile and high-performing material for diverse industries.
| Size (mm) | Weight per (Kg) | Size (mm) | Weight per (Kg) |
|---|---|---|---|
| 2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
| 3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
| 3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
| 2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
| 3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
| 2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
| 2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
| 2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
| 2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
| 3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
| 2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
Yes, we offer custom sizes for Titanium Grade 5 Foils to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Titanium Grade 5 Foils find extensive use across industries that demand material with light weight strength, toughness, and corrosion resistance. In aerospace, it is applied for airframe structures, turbine blades, and fasteners where weight reduction and mechanical strength are paramount. In the medical industry, the foil is perfectly suited for implants, prosthetics, and surgical tools because of its biocompatibility. It’s used by the automotive and motorsport industries for engine parts and exhaust systems and by marine and chemical processing industries for its application in corrosive environments. It’s also used in electronics and sports equipment that need to be made of lightweight, durable materials.
