Nial Sheets and Plates is a reputable manufacturer and supplier of top-notch Stainless Steel 310 Sheets and Plates based in Houston, USA. We cater to industries that require exceptional high-temperature strength and oxidation resistance. Our Stainless Steel 310 Sheets and Plates are meticulously crafted for structural and fabrication projects in extremely hot conditions. With our stringent quality control, cutting-edge production methods, and dependable delivery, we empower clients in sectors like furnace, heat treatment, petrochemical, and power generation to successfully complete critical projects using our durable and stable Stainless Steel 310 Sheets and Plates, designed to perform under intense heat and thermal stress.
Stainless Steel 310 Sheets and Plates are a type of high-chromium, high-nickel austenitic stainless steel, featuring around 24–26% chromium and 19–22% nickel. This unique blend provides remarkable resistance to oxidation, scaling, and high-temperature corrosion. They boast a tensile strength ranging from about 520–750 MPa and a yield strength close to 205 MPa, along with excellent creep resistance and toughness. These characteristics make Stainless Steel 310 an ideal choice for applications that experience frequent thermal cycling and sustained high temperatures, reaching up to 1100°C in continuous service.
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 max | 19.00 – 21.00 | 54.7 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 310 sheet and plate offer exceptional mechanical advantages. Their high chromium and nickel content ensures excellent resistance to oxidation, corrosion and scaling at temperatures up to 1150°C. These sheets and plates are durable, durable, and provide mechanical stability under thermal cycling. They exhibit excellent weldability and formability, making them easy to manufacture in complex structures. Additionally, they operate reliably in turbulent environments, including chemical processing plants, heat exchangers and furnaces. Their low maintenance and long life make them cost-effective and reliable for complex applications.
You’ll find Stainless Steel 310 Sheets and Plates widely utilized in scenarios that demand high-temperature strength and oxidation resistance. They are often used in constructing furnace components, heat exchanger baffles, combustion chambers, and kiln linings. Petrochemical and refinery plants rely on them for burner assemblies, flue gas ducting, and thermal processing equipment. In the power generation sector, they are essential for boiler parts and superheater tubes. Additionally, they are suitable for food processing, chemical processing, and other high-heat structural or fabricated components. Their ability to resist scaling and maintain strength in extreme heat makes Stainless Steel 310 Sheets and Plates a trustworthy material for the most challenging thermal environments.
