Nial Sheets and Plates, Houston, USA, is a reliable manufacturer and world exporter of high-grade metal sheets and plates for various industrial and commercial uses. Among its superior range is Stainless Steel 253MA Sheets and Plates, a specialty alloy designed for superior high-temperature strength, oxidation resistance, and long-term strength. Tailored especially for challenging thermal conditions, these plates and sheets are the perfect choice for application in petrochemical plants, power generation plants, and heat treating plants. With state–of-the-art manufacturing technology coupled with an emphasis on quality assurance and customer fulfillment, Nial provides solutions that fulfill strict international standards.
Stainless Steel 253MA Sheets and Plates (UNS S30815) consist of about 21% Chromium, 11% Nickel, 1.7% Silicon, and 0.08% Carbon, with minor Nitrogen, Manganese, and Cerium contents. These constituents support the alloy‘s resistance against oxidation, creep strength, and thermal fatigue performance. The material has a tensile strength of 600 MPa, yield strength of 310 MPa, and elongation of 40%, maintaining superior formability and structure stability mechanically. Capable of withstanding temperatures of up to 1150°C, this alloy functions efficiently under thermal cycling conditions and is thereby very well adapted to harsh heat environments.
| Grade | 253 MA| UNS S30815 |
| Standard | ASTM A240 / ASME SA240 |
| Thickness | 0.1mm To 100 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
| Applications | Off-Shore Oil Drilling Companies, Power Generation, Petrochemicals, Gas Processing, Specialty Chemicals, Pharmaceuticals, Pharmaceutical Equipment, Chemical Equipment, Sea Water Equipment, Heat Exchangers, Condensers, Pulp and Paper Industry |
| Grade | C | Mn | Si | S | Ce | Ni | Cr | P |
| 253 MA | 0.05 – 0.10 | 0.80 max | 1.40 – 2 | 0.030 max | 0.03 – 0.08 | 10 – 12 | 20 – 22 | 0.040 max |
| Density | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.8 g/cm3 | MPa -600 | MPa – 310 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
DIN 1.4835 Sheets and Plates offer outstanding advantages, including exceptional oxidation resistance up to 1150°C, making them ideal for high-temperature applications. Their balanced composition enhances creep resistance and ensures durability under thermal cycling. The addition of silicon and nitrogen improves strength and ductility, while cerium boosts stability in oxidizing environments. These sheets are easy to fabricate and weld, reducing production challenges. With superior corrosion resistance and excellent mechanical properties, they are highly suitable for applications in petrochemical plants, heat exchangers, and furnace components, ensuring reliability and long service life.
| Surface finish | Thickness (in) | Width (in) |
|---|---|---|
| 1 – Stainless Steel 253 MA Hot rolled, heat treated, pickled Plate & Sheet | .1000 – .3750 | max. 72 |
| 2R – Stainless Steel 253 MA Cold-rolled, bright-annealed Sheet & Plate | 0.002–0.06 | 0.118–25.551 |
| 2H – Stainless Steel 253 MA Work hardened Plate & Sheet | 0.002–0.06 | 0.118–24.803 |
| 2B – Stainless Steel 253 MA Cold rolled, heat treated, pickled, skin passed Sheet & Plate | 10–24 | max. 72* |
| 2D – Stainless Steel 253 MA Cold rolled, heat treated, pickled Plate & Sheet | 12–24 | max. 60 |
| BA Mexinox only | 18–28 | max. 48 |
| Deco Rolled-On Mexinox only | 14–28 | max. 48 |
| Stainless Steel 253 MA Polished Plate & Sheet (not brushed) | 11–24 | max. 60 |
| Temper rolled Mexinox only | 13–29 | max. 48 |
| STANDARD | WERKSTOFF NR. | UNS | SS | EN |
| 253 MA | 1.4835 | S30815 | 2368 | X9CrNiSiNCe21-11-2 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS / COILS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
Stainless Steel 253MA Sheets and Plates find extensive application in thermal processing and high-temperature industrial processes. Due to their high oxidation resistance, creep strength, and thermal fatigue resistance, they are well suited for heat exchangers, boiler parts, kiln liners, and furnace linings. In the petrochemical industry, they are used in reformer tubes, radiant coils, and catalyst supports. Power generation, cement, and waste incineration industries also take advantage of their durability in flue gas systems and other hostile, high-temperature environments. The sheets have long-lasting performance and dimensional stability, even in harsh stress and corrosive environments.
