Nial Sheets and Plates, based in Houston, USA, is a trusted name when it comes to manufacturing and supplying top-notch Stainless Steel 305 Angle products. We pride ourselves on precision, reliability, and keeping our customers happy, providing stainless steel angles that meet the rigorous demands of both industrial and commercial sectors. Stainless Steel 305 is known for its impressive corrosion resistance and excellent formability, making it a go-to choice for deep drawing and intricate fabrication projects. At Nial Sheets and Plates, we’re dedicated to delivering durable, high-performance products, along with expert support and prompt delivery to industries all over the United States.
Stainless Steel 305 Angle is an austenitic stainless steel that contains around 17–19% chromium and 10.5–13% nickel. It has a very low carbon content (maximum 0.12%) and boasts higher nickel levels compared to 304, which enhances its resistance to corrosion and oxidation. In terms of mechanical properties, it offers a tensile strength of about 585 MPa and a yield strength of around 240 MPa, with an elongation of 40%. Its standout feature is its superior formability, particularly for deep drawing and cold working processes, all while maintaining solid structural stability and corrosion resistance.
| Specifications | ASTM A240 / ASME SA240 | ||||||
| Thickness | 0.5mm-100mm | ||||||
| Outer diameter | 10mm, 25.4mm, 38.1mm, 50.8mm, 100mm, 250mm, 300mm, 350mm, etc | ||||||
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | ||||||
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | ||||||
| Finish | Hot rolled (HR), Cold rolled Tube (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | ||||||
| Form | Round tube Square tube Rectangular tube etc. | ||||||
| Grade | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness | |
| Rockwell B (HRB) | Brinell (HB) | ||||
| 305 | 480 | 177 | 40 | 90 | 187 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 305 | Min. | / | / | / | / | / | 17 | / | 10.5 | / |
| Max. | 0.12 | 2 | 0.75 | 0.045 | 0.03 | 19 | / | 13 | / |
| ASTM | UNS No. | ISO | Euronorm | China GB | Japanese JIS | ||
| No. | Name | ||||||
| 305 | S30500 | X6CrNi 18-12 | 1.4303 | X6CrNi 18-12 | 10Cr18Ni12 | SUS 305 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nial Sheets and Plates based in Houston, USA, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 305 angle offers many advantages, including excellent corrosion resistance, excellent strength and durability, especially in areas prone to moisture and dampness, and makes it ideal for construction applications. The alloy’s corrosion and stain resistance makes it durable, and requires little maintenance. Stainless steel 305 also exhibits excellent formability, making it easy to fabricate and weld. In addition, it stays in shape for a long time due to its non-reactive surface. This makes it suitable for industries such as construction, automotive and marine, where high-performance materials are important.
Stainless Steel 305 Angles are perfect for applications that demand excellent formability and corrosion resistance. You’ll often find them in the production of deep-drawn parts like kitchen sinks, appliance housings, and food processing equipment. In the automotive industry, they’re used for trims, moldings, and components that need precise shaping. Thanks to its non-magnetic properties, this alloy is also great for electronic and instrumentation applications. Plus, 305 Angles are utilized in architectural fittings, chemical equipment, and marine hardware, providing both aesthetic charm and dependable performance in mildly corrosive environments.
