Nial Sheets and Plates is a reputable manufacturer and supplier of SA537 Class 2 Boiler Sheets and Plates based in Houston, USA. They’ve built a solid reputation for providing top-notch carbon-manganese-silicon steel plates specifically designed for pressure vessel and boiler applications. Nial caters to industries that require dependable performance in high-pressure and high-temperature environments. With a strong commitment to ASME standards, meticulous fabrication, and timely delivery, the company offers SA537 Class 2 Sheets and Plates that prioritize safety and durability. Nial Sheets and Plates plays a vital role in essential sectors like oil and gas, petrochemical, and power generation by delivering reliable boiler-quality steel solutions.
SA537 Class 2 Boiler Sheets and Plates are crafted from carbon-manganese-silicon steel, tailored for pressure vessel applications. These plates typically feature around 0.24% carbon, 1.10–1.50% manganese, and 0.13–0.45% silicon, with minimal phosphorus and sulfur content to boost weldability and toughness. They boast impressive tensile strength ranging from 485–620 MPa and a minimum yield strength of about 345 MPa. Heat treatment through normalizing and quenching or tempering enhances their impact resistance, toughness, and durability, making them ideal for pressure vessels that operate under elevated pressures.
Grade : ASME SA 537 CL.2 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for Boilers and Pressure Vessels Application.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Tensile (MPa) | Yield (MPa) | Elongation |
| SA537 Class 2 | Quenched and tempered | 550–690 | 415 | 22% |
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA537 Class 2 boiler sheet and plate offer excellent strength and durability, making them ideal for pressure vessels and boiler applications. They are heat-treated to improve their hardness, ensuring resistance to high-pressure environments and elevated temperatures. The material demonstrates excellent weldability, enabling easy fabrication into complex shapes. Its resistance to corrosion and cracking under stress makes it suitable for harsh industrial environments. Additionally, SA537 Class 2 provides good toughness and impact resistance, ensuring long-term reliability in demanding applications such as power plants and chemical processing.
You’ll find SA537 Class 2 Boiler Sheets and Plates commonly used in the construction of pressure vessels, heat exchangers, reactors, and storage tanks that need to endure moderate to high temperatures and pressures. These plates are prevalent in oil and gas refineries, petrochemical plants, and power generation facilities, ensuring the safe storage and management of pressurized gases and liquids. They’re also utilized in offshore platforms and thermal power projects, where exceptional notch toughness and weldability are essential. With their reliable performance and safety features, SA537 Class 2 plates are a go-to choice for critical boiler and vessel construction.
