Nial Sheets and Plates is a leading manufacturer and supplier based in Houston, USA, specializing in high-quality sheets and plates for various industrial applications. We are committed to excellence and provide a comprehensive range of products, including Nickel Alloy 201 Sheets and Plates, known for their exceptional corrosion resistance, high-temperature stability, and outstanding mechanical properties. Our Nickel Alloy 201 products are engineered to meet the rigorous demands of industries such as chemical processing, aerospace, and marine, ensuring reliability and performance.
Nickel Alloy 201 (UNS N02201) is composed primarily of nickel (99%) with small amounts of copper, iron, manganese, silicon, and carbon. This composition provides excellent corrosion resistance, particularly in reducing environments. The mechanical properties of Nickel Alloy 201 include a tensile strength of 55-75 ksi (379-517 MPa), yield strength of 30-50 ksi (207-345 MPa), and elongation of 30-40%. The alloy exhibits good thermal and electrical conductivity and excellent formability and weldability, making it suitable for use in industries requiring resistance to corrosion at moderate temperatures.
| Grade | Nickel Alloy 201 | UNS N02201 |
| Standard | ASTM B162 / ASME SB162 |
| Size | 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm, 2010 mm x 4000 mm |
| Thickness | 0.1mm To 100 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Plain Sheet, Shim Sheet, Strip, Flats |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Sheets and Plates offer excellent corrosion resistance, particularly in acidic and alkaline environments. They are highly resistant to oxidation and possess superior thermal and electrical conductivity. These alloys are known for their excellent formability, allowing easy shaping and welding. With outstanding mechanical properties at high and low temperatures, Nickel Alloy 201 is ideal for chemical processing, heat exchangers, and electronics applications. It also provides strength and stability, making it suitable for harsh environments and high-stress applications.
|
Nickel 201 plate Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.134″ |
3.40 |
|
.125″ |
3.18 |
|
.187″ |
4.75 |
|
.156″ |
3.96 |
|
.312″ |
7.92 |
|
.250″ |
6.35 |
|
.500″ |
12.7 |
|
.375″ |
9.53 |
|
.600″ |
15.9 |
|
.875″ |
22.2 |
|
.750″ |
19.1 |
|
1″ |
25.4 |
|
3″ |
76.2 |
|
1.250″ |
31.8 |
|
1.125″ |
28.6 |
|
1.500″ |
38.1 |
|
2″ |
50.8 |
|
1.750″ |
44.5 |
|
2.500″ |
63.5 |
Nickel Alloy 201 sheets and plates are widely used in industries requiring excellent corrosion resistance, particularly in acidic environments. They are ideal for chemical, food, and electronics applications. Due to their resistance to oxidation and high-temperature stability, these alloys are frequently utilized in heat exchangers, tanks, piping systems, and reactors. Nickel Alloy 201 is also used in the manufacturing of battery components, electrical and electronic components, and applications involving severe environments, such as marine and aerospace industries.
