Nial Sheets and Plates, Houston, USA, is a reliable manufacturer and exporter of high-quality metal products, providing a wide variety of sheets, plates, and circles to cater to a large number of industries. One of our top-selling products is the Monel K500 Circle, which is renowned for its strong strength, corrosion resistance, and durability. Engineered to survive the demands of marine, chemical, and aerospace environments, this alloy delivers the topmost standards of performance. Supported by accurate engineering, aggressive pricing, and on-time delivery, Nial is your trusted business ally for every Monel K500 Circle need in domestic as well as foreign markets.
Monel K500 Circle (UNS N05500 / DIN 2.4375) is a nickel-copper alloy containing around 63% nickel, 27–33% copper, with 2.3–3.15% aluminum and 0.35–0.85% titanium additions. Tiny amounts of iron (maximum 2%) and carbon (0.25%) are also included. This composition develops increased hardness and mechanical strength through precipitation hardening. It provides tensile strength of 965 MPa, yield strength of 690 MPa, and 20% elongation with outstanding corrosion resistance, stress corrosion cracking resistance, and oxidation resistance, particularly in seawater and high-temperature industrial applications.
| Standard | ASTM B127, ASME SB127 |
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Thickness | 1 Mm To 100 mm. |
| Diameter | Upto 2000 Mm. |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max. |
| Circles Form | Cold Rolled, Small Flat, Industrial, Proof Machined, Perforated, Forged Steel, Hot Rolled Circle. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
DIN 2.4375 Circle offers numerous advantages, including superior strength and hardness due to the addition of aluminum and titanium. Its excellent corrosion resistance in harsh marine, chemical, and high-temperature environments makes it ideal for demanding applications. The alloy also resists stress corrosion cracking, pitting, and crevice corrosion, ensuring long-lasting performance. Monel K500 maintains stability under extreme conditions and exhibits excellent fatigue and impact resistance. Its high durability, combined with good weldability and machinability, makes it a reliable choice for use in aerospace, marine, and chemical processing industries.
Yes, we offer custom sizes for Monel K500 Circle to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| STANDARD | WERKSTOFF NR. | UNS |
| Monel K500 | 2.4375 | N05500 |
Monel K500 Circles find extensive applications in industries that demand superior strength, corrosion resistance, and thermal stability. In the marine sector, they are applied to propeller shafts, seawater pumps, and components under water subject to extreme conditions. In the aerospace industry, they are utilized in turbine blades, compressor blades, and engine parts, where performance under high-temperature conditions is imperative. Chemical processing industry depends on these circles for valves, heat exchangers, and reactors that come into contact with aggressive chemicals. With superb stress cracking resistance and acid-resistant properties, Monel K500 Circles are a sine qua non in oil & gas, defense, and power generation industries.
