Nial Sheets and Plates, Houston, USA-based, is a reputed manufacturer and supplier of high-quality metal products like sheets, plates, and circles designed to meet a wide range of industrial needs. Among our specialty items is the Monel 400 Circle (DIN 2.4360), well known for its excellent corrosion resistance, particularly in the marine and chemical processing industries. With a great focus on precision engineering, ruggedness, and customer satisfaction, we make sure every product meets high industry standards. Our promise to deliver products on time, at competitive rates, with assured performance makes us a customer choice in marine, chemical, oil & gas, and ancillary industries.
Monel 400 Circle (DIN 2.4360) is a nickel-copper alloy consisting of around 63% nickel and 28–34% copper, with iron (up to 2.5%), manganese (2%), and carbon (0.3%). The composition ensures excellent corrosion resistance in seawater, acidic, and alkaline environments. It offers tensile strength of 550–700 MPa, yield strength of 240–345 MPa, and elongation of 30%, ensuring better ductility and strength under stress. Monel 400, with its melting point range of 1300–1350°C, provides structural stability at high temperatures and is well suited for industrial applications involving high pressures and corrosion.
| Standard | ASTM B127, ASME SB127 |
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Thickness | 1 Mm To 100 mm. |
| Diameter | Upto 2000 Mm. |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max. |
| Circles Form | Cold Rolled, Small Flat, Industrial, Proof Machined, Perforated, Forged Steel, Hot Rolled Circle. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Ni | C | Al | Mn | Si | Fe | Cu | S |
| Monel 400 | 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
| Property | Value |
|---|---|
| Tensile Strength | 70-95 ksi (485-655 MPa) |
| Yield Strength | 30 ksi (205 MPa) min |
| Elongation | 35% min in 2 inches (50 mm) |
| Hardness | Rockwell B70 max |
| Modulus of Elasticity | 28 x 106 psi (193 GPa) |
| Poisson’s Ratio | 0.31 |
UNS N04400 Circle offers several advantages, including outstanding corrosion resistance in marine and chemical environments, making it ideal for seawater applications. Its high strength and durability ensure long-lasting performance under stress and high temperatures. The alloy’s resistance to pitting, crevice corrosion, and stress corrosion cracking makes it highly reliable in harsh conditions. Monel 400 is also known for its excellent thermal conductivity and machinability, making it easy to fabricate. Its versatility extends across a variety of industries, including marine, chemical processing, and aerospace, ensuring it meets demanding requirements while offering superior performance.
Yes, we offer custom sizes for Monel 400 Circle to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Outer Diameter (OD) (mm) | Thickness (mm) | Size (mm) | Approximate Weight (kg) |
|---|---|---|---|
| 100 | 5 | 100 x 5 | 3.92 |
| 150 | 10 | 150 x 10 | 17.66 |
| 200 | 15 | 200 x 15 | 39.26 |
| 250 | 20 | 250 x 20 | 68.83 |
| 300 | 25 | 300 x 25 | 107.36 |
| 350 | 30 | 350 x 30 | 154.87 |
| 400 | 35 | 400 x 35 | 211.35 |
| 450 | 40 | 450 x 40 | 276.80 |
| 500 | 50 | 500 x 50 | 392.70 |
| Property | Value |
|---|---|
| Density | 8.80 g/cm³ |
| Melting Point | 1,455°C (2,651°F) |
| Electrical Resistivity | 0.49 µΩ·cm |
| Thermal Conductivity | 35.4 W/m·K |
| Thermal Expansion (25-100°C) | 13.4 µm/m·K |
| Specific Heat (at 25°C) | 0.385 J/g·K |
| Young’s Modulus | 193 GPa (28 x 10⁶ psi) |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Monel 400 Circle is widely used in industries where corrosion resistance, heat stability, and mechanical strength are essential. In the marine industry, they are well suited for propeller shafts, seawater pumps, heat exchangers, and valves, and provide long-time resistance in seawater conditions. In chemical processing, Monel 400 is applied to reactors, storage tanks, and piping systems handling severe acids and alkalis. The aerospace industry uses it in turbine engine components, while the petroleum and gas industry uses it in drilling equipment, pipelines, and wellhead gear. Its success in hostile environments makes it a leading selection across these high-stakes applications.
