Nial Sheets and Plates, Houston, USA, is a leading producer and supplier of high–grade sheets, plates, and foils for industrial purposes. Nickel Alloy 201 Foil is one of our high-grade products, a product widely admired for its superior corrosion resistance, thermal stability, and mechanical strength. Designed to withstand the stringent requirements of industries like chemical processing, electronics, and aerospace, the foils provide endurance and performance in vital applications. Supported by innovative technology and customer-centric philosophy, Nial Sheets and Plates is your one-stop shop for high-performance metallurgical solutions. The best.
Nickel Alloy 201 Foils consist of 99% pure nickel with trace amounts of manganese, copper, iron, and carbon, which are good for excellent corrosion resistance—especially in alkaline and reducing conditions. The alloy has superior ductility, good weldability, and retains mechanical properties at low and high temperatures. Significant mechanical properties are tensile strength of 380–520 MPa, yield strength of 140–210 MPa, and elongation of 30–50%. Its low magnetic permeability and thermal conductivity qualify it for uses requiring stability, conductivity, and formability under changing industrial conditions.
Specifications : ASTM B168 / ASME SB168
Size : 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm
Form : Foils, Rolls
Thickness : 0.1mm to 12 mm Thk
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
Other services : Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 foils offer exceptional corrosion resistance, particularly in alkaline environments, making them ideal for chemical processing applications. They exhibit excellent thermal and electrical conductivity, high strength, and ductility, ensuring reliability under various conditions. The alloy maintains excellent formability and weldability, allowing easy fabrication into thin, durable foils. Nickel Alloy 201 also resists oxidation and is highly resistant to stress corrosion cracking, making it suitable for applications in marine, aerospace, and electrical industries where longevity and performance are crucial.
Nickel Alloy 201 Foils find extensive use in industries necessitating corrosion resistance in high levels, particularly in chemical process, electronic, and aerospace industries. They are best suited for heat exchangers, valves, and reactors used in alkaline or acidic processes, providing durability against harsh chemical exposure. They are utilized in resistors, battery parts, and electrical connections in the electronics sector because of their electrical and thermal conductivity. Their non-reactive nature further makes them ideal for use in food processing hardware. Their low gas level, magnetic neutrality, and dimensional stability provide stable performance in precision and high-temperature uses.
