Nial Sheets and Plates, Houston, USA, is a world-famous manufacturer and supplier of top-quality metal products, providing high-performance solutions to businesses worldwide. One of our specialized products is the Nickel Alloy 200 Channel, which is characterized by its high corrosion resistance, excellent mechanical strength, and superior thermal and electrical conductivity. With a firm dedication to quality and innovation, we guarantee our products reach international standards and provide superior performance in harsh conditions. Our Nickel Alloy 200 Channels are offered in multiple sizes, making Nial the go-to company for industries needing dependable, long-lasting, and accurately engineered materials.
Nickel Alloy 200 Channel consists of 99% pure nickel and trace elements of manganese, iron, and copper to improve certain properties. This alloy has superior corrosion resistance, especially in alkaline and acidic conditions. The alloy also possesses high thermal and electrical conductivity, good formability, and weldability. The alloy has a tensile strength of 35–80 ksi (240–550 MPa) and yield strength of 15–30 ksi (100–200 MPa), with good ductility. All these make it very appropriate for demanding industrial use involving chemical exposure and high operating temperatures.
Specifications : ASTM B160 / ASME SB160
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 200 Channel offers several advantages, including exceptional corrosion resistance, particularly in alkaline environments and organic acids. It maintains strength and toughness at high and low temperatures, making it ideal for demanding applications. Its excellent weldability and formability provide versatility in manufacturing, and its resistance to various forms of corrosion, such as pitting and crevice corrosion, ensures longevity and reliability. Additionally, it offers superior resistance to atmospheric oxidation and maintains high thermal and electrical conductivity, making it suitable for industries like chemical processing and electronics.
Nickel Alloy 200 Channels find vast usage in industries requiring corrosion resistance as well as temperature stability. They are well suited for heat exchangers, piping systems, valves, and storage tanks in chemical processing to deal with corrosive materials. Sanitary equipment in the food and beverage industry makes use of this alloy because of its non-reactive property. Pump components and seawater handling systems in marine environments employ this alloy. It is also used in power generation and aviation, where it needs to be strong and resistant to heat and stress. Its conductivity also renders it useful in electronics and battery production.
