Incoloy 825 Sheets and Plates

Nial Sheets and Plates stands out as a top-notch manufacturer and supplier of Incoloy 825 Sheets and Plates, proudly based in Houston, USA. We focus on providing high-performance nickel-iron-chromium alloy products that are specifically engineered for exceptional corrosion resistance in some of the toughest environments. Our Incoloy 825 Sheets and Plates are crafted to meet international standards, ensuring precise dimensions, a flawless surface finish, and impressive mechanical properties. These products are widely trusted across various industries, including chemical processing, pollution control, nuclear fuel reprocessing, and marine engineering, thanks to their reliability and long-lasting performance. Nial Sheets and Plates is dedicated to serving clients throughout the USA and around the globe, offering timely deliveries and outstanding customer support.

Incoloy 825 Sheets Dealer in Los Angeles, Incoloy 2.4858 Plates Supplier in Los Angeles, Incoloy 825 Sheets in Texas, 825 Incoloy Plates Size Chart, Incoloy 825 Sheet Price in California, Incoloy 825 Plates Supplier in United Kingdom, 825 Incoloy Sheet Stockist in Houston , 825 Incoloy Alloy Sheets and Plates Exporter in USA, Incoloy 825 Sheet Stockist in Houston, Incoloy Plates Supplier in Houston

Incoloy 825 Cold Rolled Plates

Incoloy 825 Hot Rolled Plates

Incoloy 825 Clad Sheets and Plate

The composition of Incoloy 825 Sheets and Plates includes nickel (38–46%), iron (at least 22%), chromium (19.5–23.5%), molybdenum (2.5–3.5%), copper (1.5–3%), along with trace amounts of titanium and aluminum. This alloy is known for its remarkable resistance to a variety of corrosive environments, such as sulfuric and phosphoric acids, seawater, and both oxidizing and reducing agents. Typically, it boasts a tensile strength of 550–700 MPa, a yield strength ranging from 220–350 MPa, and an elongation of up to 30–45%. Incoloy 825 retains its strength and corrosion resistance even at temperatures reaching 540°C (1000°F), making it a great choice for both acidic and high-temperature applications.

Incoloy 825 Sheets and Plates Specification

Specifications:	ASTM / ASME SB 168, ASTM / ASME SB 424 , ASTM / ASME SB 443
Thickness:	4 mm To 100 mm
Length:	2000mm, 2438mm, 3000mm, 5800mm, 6000mm,12000mm，or as required
Width:	40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,or as required
Grade	800/ 800H/ 800HT/ 825
Application	Building industry,architectural decoration,elevators,building doors,panels and so on.
Standard:	ASTM，AISI，JIS，GB， DIN，EN
Surface:	BA，2B，NO.1，NO.4，4K，HL，8K
Certification:	ISO, SGS，BV
Technique:	Cold Rolled Hot Rolled
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form	Sheets, Plates, Coils, Slatting Coils, Perforated Coils

Incoloy 825 Sheet and Plate Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
825	0.05 max	1.00 max	0.5 max	0.03 max	1.50 – 3.00	22.00 min	38.00 – 46.00	19.50 – 23.50	0.02 max	0.06 – 1.20

Alloy 825 Sheet and Plate Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
825	8.14 g/cm3	1400 °C (2550 °F)	Psi – 80,000 , MPa – 550	Psi – 32,000 , MPa – 220	30 %

Equivalent Grades for 825 Incoloy Sheet and Plates

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN	OR
Incoloy 825	2.4858	N08825	NCF 825	NA 16	ЭП703	NFE30C20DUM	NiCr21Mo	XH38BT

825 Incoloy Sheets Price in California, 825 Incoloy Hot Rolled Weight Chart, Incoloy N08825 Cold Rolled Supplier in United Kingdom, Stockist of Incoloy 825 Alloy Cold Rolled Sheets in Houston , 825 Incoloy Perforated Sheet Supplier in USA, Incoloy 825 Perforated Plates Price List in Houston, Alloy Perforated Plates Supplier in Houston , Incoloy 825 Chequered Plates Exporter in Los Angeles, Incoloy Alloy 825 Polished Plates Exporter in USA, 825 Incoloy Perforated Plates Exporter in Texas, 825 Incoloy Sheet and Plate in California

Weight Chart of 825 Incoloy Alloy Sheets and Plates

Thickness	Plate Weight per Unit Area	Density
3/16 inches	0.06000 lbs/in²42.184176 kg/m²	0.315 lbs/in³8.72 g/cm³
1/4 inches	0.08 lbs/in²56.245568 kg/m²	0.315 lbs/in³8.72 g/cm³
3/8 inches	0.121 lbs/in²85.0714216 kg/m²	0.315 lbs/in³8.72 g/cm³
1/2 inches	0.161 lbs/in²113.1942056 kg/m²	0.315 lbs/in³8.72 g/cm³
5/8 inches	0.196 lbs/in²137.8016416 kg/m²	0.315 lbs/in³8.72 g/cm³
3/4 inches	0.235 lbs/in²165.221356 kg/m²	0.315 lbs/in³8.72 g/cm³
7/8 inches	0.274 lbs/in²192.6410704 kg/m²	0.315 lbs/in³8.72 g/cm³
1 inches	0.313 lbs/in²220.0607848 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/4 inches	0.391 lbs/in²274.9002136 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/2 inches	0.47 lbs/in²330.442712 kg/m²	0.315 lbs/in³8.72 g/cm³
1 3/4 inches	0.549 lbs/in²385.9852104 kg/m²	0.315 lbs/in³8.72 g/cm³
2 inches	0.627 lbs/in²440.8246392 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/4 inches	0.705 lbs/in²495.664068 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/2 inches	0.784 lbs/in²551.2065664 kg/m²	0.315 lbs/in³8.72 g/cm³
2 3/4 inches	0.862 lbs/in²606.0459952 kg/m²	0.315 lbs/in³8.72 g/cm³
3 inches	0.941 lbs/in²661.5884936 kg/m²	0.315 lbs/in³8.72 g/cm³

Incoloy 825 Plate Size

Incoloy 825 Plates STOCKED SIZES
SIZE	ALLOY 825	SIZE
.125″	X	3.18mm
.134″		3.40mm
.156″	X	3.96mm
.187″	X	4.75mm
.250″	X	6.35mm
.312″	X	7.92mm
.375″	X	9.53mm
.500″	X	12.7mm
.625″	X	15.9mm
.750″	X	19.1mm
.875″		22.2mm
1″	X	25.4mm
1.125″		28.6mm
1.250″	X	31.8mm
1.500″	X	38.1mm
1.750″	X	44.5mm
2″	X	50.8mm
2.500″	X	63.5mm
3″		76.2mm

If You Are Looking To Buy High Quality Piping Products ?

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Largest Incoloy 825 Sheet and Plates Manufacturer and Exporter in Houston, USA

Nial Sheets and Plates based in Houston, USA, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.

DIN 2.4858 Incoloy Clad Sheets Distributor in USA, 825 Incoloy Perforated Plates Supplier in Houston, 825 Incoloy Perforated Sheet Weight Chart, Incoloy 825 Plate Exporter in Houston , 825 Incoloy Polished Sheets Manufacturer in Los Angeles, Incoloy 825 Shim Sheet and Plate Price List in United Kingdom, 825 Incoloy Chequered Plates Sizes in mm, Incoloy Alloy 825 Hot Rolled Plate Distributor in Texas, 825 Incoloy Sheets and Plates California

Incoloy 825 sheets and plates have many advantages, making them ideal for complex applications. Anti-corrosion properties, especially in acid and sulfur environments, ensure exceptional durability. The high strength and excellent fatigue resistance of the compound ensures reliability under stress. Incoloy 825 maintains high thermal integrity and provides excellent weldability. It also provides outstanding compression resistance against stress corrosion cracking and pitting. These features make Incoloy 825 sheets and plates ideal for use in the pharmaceutical, marine environment, aerospace and nuclear industries, providing unparalleled performance and longevity

Types of Incoloy 825 Sheet and Plates

UNS N08825 Incoloy Plates Manufacturer in Los Angeles, 825 Incoloy Plates and Sheets Texas, Incoloy 825 Mirror Finish Plates Supplier in Houston, 825 Incoloy Polished Plates Exporter in Houston , Incoloy 825 Alloy Chequered Plates Price List in United Kingdom, Incoloy 825 Cold Rolled Plate Distributor in Texas, 825 Incoloy Clad Plates and Sheets Supplier in Los Angeles, Incoloy 825 Sheet and Plate Distributor in USA, 825 Incoloy Perforated Plate Sizes in mm

Are Custom Sizes Available for Incoloy 825 Sheet and Plates?

Yes, we offer custom sizes for Incoloy 825 Sheet and Plates to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of Incoloy 825 Sheet and Plates

Incoloy 825 Sheets and Plates are commonly utilized in situations that demand outstanding corrosion resistance under challenging conditions. You’ll find them in chemical tanks, heat exchangers, scrubbers, acid production equipment, marine exhaust systems, oil and gas piping, and pollution control systems. Its stability in both oxidizing and reducing environments makes it perfect for managing mixed chemical media and contaminated acids. Nial Sheets and Plates offers Incoloy 825 Sheets and Plates in a variety of thicknesses, widths, and finishes, ensuring customized solutions that meet the rigorous demands of our clients.
