Offering dependable, high-strength carbon steel solutions for engineering and industrial applications, Nial Sheets and Plates is a top producer and supplier of C50 High Carbon Steel Sheets and Plates in Houston, USA. After heat treatment, C50, a medium-to-high carbon steel, is renowned for its exceptional strength, hardness, and resistance to wear. To satisfy the needs of the construction, tooling, and automotive industries, we provide C50 sheets and plates in a range of thicknesses, finishes, and custom dimensions. For manufacturing needs that are performance-critical, Nial focusses on providing precision-cut, quality-assured steel products with quick turnaround times and affordable prices.
The typical composition of C50 High Carbon Steel Sheets and Plates is manganese (0.60–0.90%), carbon (0.47–0.55%), and trace amounts of silicon, sulphur, and phosphorus. Especially after heat treatment, this composition provides a good balance between toughness and wear resistance. Depending on the processing and tempering conditions, the material has a yield strength of 350–500 MPa and a tensile strength of roughly 610–750 MPa. Additionally, it has good machinability and can be surface hardened by induction or flame hardening. C50’s mechanical characteristics make it ideal for components exposed to wear, stress, and moderate impact loads.
| Thickness Range | 0.10 – 5.00 MM |
| Width Range | 5.00 – 1250 MM |
| Form | Can be supplied in Coil or Sheet form |
| Sheet Length (CTL) | 300 – 3000 MM |
| Edge | Mill edge or Sheared edge |
| Coil / Sheet Pallet Weight | Weight of each Coil or Sheet pallet can be customized as per customer’s need |
| Coil ID / OD | ID or OD of each Coil can be customized as per customer’s need |
| Packing | High-end export packing for sea or road travel, completely safe during transit. Duly oiled with anti-rust oil, wrapped in hessian cloth & high-density plastic sheets to prevent moisture. Further strapped with high tensile strips. For identification & tracing, non-erasable polyester stickers are placed on each material |
| Delivery Time | Dispatched within 10 days to 2 months, depends upon the required size |
| Some Applications | Auto components such as Washers, Clutch components, various types of Springs, Pen Clips, Hanger Clips, Cycle/Motor Chains, etc. |
Element |
C |
Si |
Mn |
P |
S |
Cr |
Cu |
Ni |
Content (%) |
0.47 – 0.55 |
0.17 – 0.37 |
0.50 – 0.80 |
0.03 |
0.03 |
0.15 |
0.25 |
0.30 |
GRADE |
Tensile Strength min |
Yield Strength min |
Elongation min. |
contraction min |
impact min |
Hardness Max |
|
σb/M Pa |
σs/M Pa |
δ5/% |
ψ/% |
Akv/J |
Without heating |
annealing |
|
C50 |
630 |
375 |
14 |
40 |
31 |
241 |
207 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
C50 High Carbon Steel Plates offer numerous advantages, including superior strength and hardness, making them ideal for heavy-duty industrial applications. Their high tensile and yield strength ensure excellent load-bearing capacity, while their wear resistance provides durability in demanding environments. C50 plates also offer good machinability, allowing for easy fabrication and customization for specific applications. The steel’s exceptional toughness and ability to withstand high-stress conditions make it perfect for use in components like gears, shafts, and machinery. Additionally, C50 High Carbon Steel Plates are cost-effective, providing long-lasting performance and reliability.
Yes, we offer custom sizes for C50 High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| SAE / AISI – American | SAE 1050 |
| DIN – Germany | C50 / CK50 |
| EN – English / BS – British | – |
| JIS – Japanese | S50C |
| UNI – Italy | C50 |
Applications requiring hardness, strength, and wear resistance frequently use C50 high carbon steel sheets and plates. They are employed in the production of connecting rods, crankshafts, and gears in the automotive sector. They are used for dies, cutters, blades, and wear plates in the tooling and machinery industry. C50 steel is utilised in construction for reinforcement and structural elements that require a high degree of strength. Additionally, springs, fasteners, industrial equipment, and agricultural tools use it. C50 is an affordable material for heavy-duty applications because, when properly heat-treated, it performs exceptionally well in load-bearing and high-friction situations.
