Nial Sheets and Plates, Houston, USA, is a top-notch supplier and exporter of high-quality Super Duplex Steel Sheets and Plates. They are known for their utmost strength, top-notch corrosion resistance, and long-lasting durability, and our Super Duplex Steel sheets and plates are designed to perform under harsh conditions like marine, offshore, chemical processing, and petrochemical industries. With dedication to precision engineering, timely delivery, and tailor-made solutions, Nial ensures that each product is of or better than the client‘s expectations. We strive to deliver dependable materials that can endure extreme conditions with high structural integrity and operational effectiveness.
Super Duplex Steel Sheets and Plates have a rough estimate of 50/50 austenitic and ferritic microstructure, which provides the best of both worlds in terms of strength and toughness. The main alloying constituents are chromium (19–28%), nickel (4–7%), molybdenum (2–3%), and addition of nitrogen, copper, and tungsten for better performance. These plates provide tensile strength of 620–850 MPa, yield strength of 450–600 MPa, and elongation up to 25%. The alloy has excellent pitting resistance, crevice corrosion resistance, and stress corrosion cracking resistance and can be used in highly corrosive and high-pressure environments.
| Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Element | C | Mn | Si | P | S | Cr | Ni | Mo | N | Fe |
| Super Duplex Steel Pipe Fittings | 0.030 max. | 2.00 max. | 1.00 max. | 0.030 max. | 0.020 max. | 21.0 – 23.0 | 4.50 – 6.50 | 2.50 – 3.50 | 0.08 – 0.20 | 63.54 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Super Duplex Steel Pipe Fittings | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Super Duplex Steel Sheets and Plates offer several key advantages, making them ideal for harsh environments. Their excellent corrosion resistance, including resistance to pitting, crevice, and stress corrosion cracking, ensures long-lasting performance in marine, offshore, and chemical processing industries. With a high strength-to-weight ratio, Super Duplex Steel is both strong and durable, providing reliable performance under high-pressure conditions. It also boasts superior weldability, making it easy to fabricate into complex structures. The material’s ability to perform well in extreme temperatures and aggressive chemicals makes it a top choice for critical applications.
Yes, we offer custom sizes for Super Duplex Steel Sheet and Plates to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| STANDARD | UNS | WERKSTOFF NR. |
| Super Duplex 2507 | S32750 | 1.4410 |
| Sheet & Plate Surface finish | Gauge (in) | Width (max in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished Sheet (not brushed) | 11–24 | 60 |
| Temper rolled Sheet Mexinox only | 13–29 | 48 |
| Plate Thickness (mm) | Weight (kg/m) | kg/meter (width 1200mm) | kg/meter (width 1500mm) | kg/meter (width 1800mm) | kg/meter (width 2400mm) |
| 3 | 23.55 | 28.3 | 35.3 | 42.4 | 56.5 |
| 4 | 31.4 | 37.7 | 47.1 | 56.5 | 75.4 |
| 5 | 39.25 | 47.1 | 58.9 | 70.7 | 94.2 |
| 6 | 47.1 | 56.5 | 70.7 | 84.8 | 113 |
| 8 | 62.8 | 75.4 | 94.2 | 113 | 150.7 |
| 10 | 78.5 | 94 | 118 | 141 | 188 |
| 12 | 94.2 | 113 | 141 | 170 | 226 |
| 16 | 125.6 | 151 | 188 | 226 | 301 |
| 20 | 157 | 188 | 236 | 283 | 377 |
| 22 | 172.7 | 207 | 259 | 311 | 415 |
| 25 | 196.25 | 236 | 294 | 353 | 471 |
| 28 | 219.8 | 264 | 330 | 396 | 528 |
| 32 | 251.2 | 301 | 377 | 452 | 603 |
| 36 | 282.6 | 339 | 424 | 509 | 678 |
| 40 | 314 | 377 | 471 | 565 | 754 |
| 45 | 353.25 | 424 | 530 | 636 | 848 |
| 50 | 392.5 | 471 | 589 | 707 | 942 |
| 55 | 431.75 | 518 | 648 | 777 | 1036 |
| 60 | 471 | 565 | 707 | 848 | 1130 |
| 65 | 510 | 612 | 765 | 918 | 1224 |
| 70 | 549.5 | 659 | 824 | 989 | 1319 |
| 75 | 588.75 | 707 | 883 | 1060 | 1413 |
| 80 | 628 | 754 | 942 | 1130 | 1507 |
| 90 | 706.5 | 848 | 1060 | 1272 | 1696 |
| 100 | 785 | 942 | 1178 | 1413 | 1884 |
Super Duplex Steel Plates and Sheets find vast applications in industries calling for great mechanical strength, superior resistance to corrosion, and extended service life. In the offshore and marine industry, these find applications in ship construction, subsea pipelines, as well as platforms that are exposed to sea water. In petrochemical and chemical industries, they are suitable for reactor columns, storage tanks, pressure vessels, and heat exchangers because of their ability to resist high pressures and aggressive chemicals. Besides, they work in desalination facilities, oil and gas pipes, and structural parts where safety and longevity under harsh conditions are paramount.
