Nial is a reliable manufacturer and supplier of Rene 41 Sheets and Plates, proudly based in Houston, USA. They cater to a wide range of industrial needs with their precisely engineered superalloy products. With a strong emphasis on quality, performance, and customer satisfaction, Nial provides Rene 41 sheets and plates that adhere to strict international standards. These products are celebrated for their exceptional strength, high-temperature resistance, and impressive corrosion performance, making them perfect for applications in aerospace, defense, and chemical processing. Thanks to Nial’s state-of-the-art facilities and skilled workforce, they ensure timely delivery and dependable service, which has helped them build a solid reputation in the high-performance materials market.
Rene 41 is a nickel-based superalloy, primarily made up of nickel (around 55%), along with chromium (19%), cobalt (11%), molybdenum (10%), and small amounts of aluminum, titanium, and carbon. This unique composition grants it excellent thermal strength and oxidation resistance. On the mechanical side, Rene 41 boasts high tensile strength that exceeds 180 ksi (1240 MPa), yield strength above 120 ksi (827 MPa), and remarkable creep rupture properties at temperatures reaching up to 1600°F (870°C). The alloy’s outstanding heat resistance and structural integrity make it a go-to choice for the most demanding environments.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nial Sheets and Plates based in Houston, USA, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Rene 41 sheets and plates offer numerous advantages, making them a preferred choice for demanding applications. They provide exceptional strength and durability, maintaining integrity under extreme temperatures and high-stress conditions. Their superior heat resistance and oxidation protection ensure long-lasting performance in environments exceeding 980°C (1800°F). With excellent corrosion resistance, Rene 41 is ideal for aerospace, power generation, and automotive industries. Its outstanding weldability and machinability enable precise fabrication for complex components. These properties make Rene 41 sheets and plates a reliable and versatile solution for critical, high-performance applications.
Yes, we offer custom sizes for Rene 41 Sheets and Plates to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Rene 41 Sheets and Plates are widely used in high-temperature and high-stress applications due to their robust mechanical and thermal performance. In the aerospace industry, they play a crucial role in manufacturing turbine engines, afterburner components, and jet exhaust systems. The alloy’s resistance to oxidation and creep makes it an excellent fit for rocket engine parts, thrust reversers, and industrial gas turbines. Moreover, Rene 41 is also utilized in nuclear reactors and chemical processing equipment, where corrosion resistance and structural reliability are paramount. Nial is committed to ensuring that each Rene 41 product delivers top-notch performance, meeting the complex demands of today’s high-temperature industries.
