Nial Sheets and Plates is a well-respected manufacturer and supplier located in Houston, USA, with a focus on high-performance alloys like Rene 41 Foil. They’ve built a reputation for providing top-notch quality and precision-engineered metal solutions, serving clients in aerospace, defense, and industrial sectors who require exceptional materials for challenging environments. Their Rene 41 Foil is highly regarded for its reliability, impressive strength, and thermal stability. With a strong commitment to customer satisfaction and rigorous quality control, Nial Sheets and Plates guarantees timely delivery and adherence to international standards, making them a go-to partner for advanced engineering projects both in the USA and around the globe.
Rene 41 Foil is a nickel-based superalloy that consists of about 19% chromium, 11% cobalt, 10% molybdenum, and the rest nickel, along with small amounts of aluminum, titanium, and carbon. It boasts excellent oxidation resistance and remarkable mechanical strength at high temperatures, reaching up to 1600°F (870°C). Rene 41 has a tensile strength that surpasses 185 ksi and a yield strength of around 140 ksi when heat-treated. Its hardness falls between 38–44 HRC, making it perfect for high-stress applications. This alloy also withstands thermal fatigue, creep, and stress-rupture deformation in extreme conditions.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nial Sheets and Plates based in Houston, USA, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Rene 41 foil offers numerous advantages, making it a preferred material for demanding applications. It excels in high-temperature environments, maintaining strength and stability up to 980°C (1800°F). The alloy’s exceptional creep resistance ensures reliability under prolonged stress, while its high tensile strength enhances durability. Rene 41 is also highly resistant to oxidation and corrosion, extending the lifespan of components in harsh conditions. Additionally, its precision and adaptability make it ideal for aerospace, gas turbines, and industrial applications requiring exceptional performance under extreme thermal and mechanical stresses.
Yes, we offer custom sizes for Rene 41 Foil to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Rene 41 Foil is widely utilized in high-temperature aerospace and jet engine components, including afterburner parts, turbine casings, fasteners, and combustion liners. Its outstanding thermal and mechanical stability makes it suitable for environments that require prolonged exposure to intense heat and stress. Furthermore, it’s used in nuclear reactors, rocket propulsion systems, and advanced automotive exhaust systems. In the medical and energy fields, Rene 41 is preferred for precision parts that need to be durable and resistant to oxidation. Its thin foil form provides lightweight solutions without sacrificing performance in critical applications.
