Nial Sheets and Plates is a reputable manufacturer and supplier located in Houston, USA, focusing on high-quality Copper Nickel 70/30 Angles. With a strong dedication to precision engineering and durability, this company provides corrosion-resistant and robust metal products that are perfect for both marine and industrial settings. Their Copper Nickel 70/30 Angles are crafted from top-notch raw materials and cutting-edge technology, guaranteeing outstanding reliability and performance. Catering to a variety of sectors across the USA and beyond, Nial Sheets and Plates has built a solid reputation for timely deliveries, custom sizing options, and exceptional customer service tailored to meet the unique needs of different projects.
| Specifications | : | ASTM B151 / ASME SB151 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Cu-Ni 70/30 Angle | : | 5mm to 9mm |
| Cu-Ni 70/30 Channel | : | 40mm*20mm~300mm*300mm |
| Cu-Ni 70/30 Beam | : | 3″ thru 12.31″ |
| Cu-Ni 70/30 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 70/30 | 2.0882 | C71500 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 70 / 30 Angle has several advantages. Its exceptional corrosion resistance, especially in seawater, makes it ideal for the marine environment. The alloy’s high resistance to biofouling and scaling ensures long-term performance in marine heat exchanger applications. CuNi 70/30 offers excellent strength, excellent ductility, and is easy to manufacture, including welding and fabrication. It has a lot of thermal expansion, which makes it stable in temperature fluctuations. The alloy is also resistant to pitting, crevice corrosion and stress corrosion cracking, providing reliability in harsh industrial marine environments
Copper Nickel 70/30 Angle is commonly utilized in scenarios that require strong resistance to seawater corrosion and marine conditions, such as shipbuilding, offshore oil rigs, and desalination facilities. It’s perfect for heat exchangers, condenser components, and seawater piping systems due to its superb thermal conductivity and resistance to biofouling. In chemical processing plants, it’s employed for managing corrosive materials. Its structural integrity and ease of fabrication also make it a go-to option for architectural and mechanical support systems in tough environments where durability and longevity are essential.
