Serving customers throughout Houston, Texas, Nial Sheets and Plates is a reputable producer and supplier of premium aluminium 5005 plates and sheets. Aluminium 5005 is widely used in both architectural and industrial applications because of its exceptional corrosion resistance, smooth finish, and versatility. To satisfy client needs, we provide an extensive selection of 5005-grade aluminium plates and sheets in a range of thicknesses, sizes, and finishes. Delivering precisely engineered products that meet international standards and offer long-term performance in demanding environments is our mission at Nial Sheets and Plates.
The aluminum-magnesium alloy known as aluminium 5005 has trace amounts of iron, silicon, and chromium in addition to about 0.8% magnesium. It provides exceptional corrosion resistance, especially in atmospheric and marine conditions, and moderate strength with a tensile range of 145–190 MPa. The alloy is perfect for anodising because it has good surface finish, formability, and weldability. Although aluminium 5005 cannot be heated, it can be cold-worked to strengthen it. It is a dependable option for both decorative and functional applications due to its mechanical qualities and chemical stability.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Chemical Properties | % Value |
| Silicon (Si) | 0.30 |
| Chromium (Cr) | 0.10 |
| Manganese (Mn) | 0.20 |
| Magnesium (Mg) | 0.5-1.1 |
| Copper (Cu) | 0.20 |
| Titanium (Ti) | – |
| Iron (Fe) | 0.7 |
| Zinc (Zn) | 0.25 |
| Aluminium (Al) | Balance |
| Property | Value |
| Proof Stress | 120 Min MPa |
| Tensile Strength | 145 – 185 MPa |
| Elongation at 50 mm | 3 Min % |
| Hardness Brinell | 47 HB |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 5005 Sheets and Plates offer numerous advantages, including excellent corrosion resistance, making them suitable for marine and outdoor environments. They have superior anodizing qualities, ensuring an attractive, durable finish ideal for architectural applications. Their lightweight nature allows for easy handling and fabrication, reducing transportation and installation costs. Aluminium 5005 demonstrates good weldability and moderate strength, providing versatility across various industries. Its non-heat-treatable but cold-workable property enhances strength when needed, making it a reliable choice for roofing, cladding, signage, and decorative applications where durability and aesthetics are key.
Yes, we offer custom sizes for Aluminium 5005 Plates and Sheets to meet specific project needs. Our team at Nial Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Standard | UNS | ISO | BS | DIN |
| 5005 | A95005 | AlMg1 | N41 | 3.3315 |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
Because of their superior corrosion resistance and beautiful finish, aluminium 5005 plates and sheets are frequently used in industrial, marine, and architectural applications. Signage, appliance panels, curtain walls, roofing, and cladding are typical applications. Because of its resistance to saltwater, it is utilised in the transportation sector for marine components and vehicle bodies. Additionally, the alloy is preferred for use in pressure vessels, storage tanks, and equipment used in food processing. It is perfect for decorative finishes in both exterior and interior design because of its exceptional anodising properties. Overall, Aluminium 5005 combines strength, appearance, and durability for a wide range of uses.
